12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator

12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator

12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator
12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator

صورة كبيرة :  12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator

تفاصيل المنتج:
اسم العلامة التجارية: Dason
إصدار الشهادات: ISO9001
رقم الموديل: T1939
شروط الدفع والشحن:
الحد الأدنى لكمية: 500
الأسعار: 10USD
وقت التسليم: 20 يوم
شروط الدفع: T/T
القدرة على العرض: 500000 جهاز كمبيوتر شخصى

12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator

وصف

Product spotlights

This 12V push-pull solenoid features a compact tubular design with a 5mm stroke and 5N force, ideal for automation applications like door locks and medical equipment. Made from durable steel and enamel wire, it supports DC power, linear motion, and voltage stroke customization. Certified with CE, RoHS, and UL for compliance with EU safety standards, ensuring global market access.
This manufacturer and trader mainly exports to Canada, the US, and Thailand, offers quality control services, and supports full customization and design customization. The products are certified. The positive review rate is 98.2% with 164 positive reviews.
This product enjoys significant popularity on Alibaba.com, driven by its competitive pricing and surging traffic.

Key attributes



Place of Origin
China
Brand Name
Dason
Model Number
TU1939
Type
push pull
Mounting Type
custom
Description
push pull tubular solenoid
Application
actuator
Duty Cycle
10%
Power (Watts)
70w
Voltage - Rated
24v
Size / Dimension
L39*D19mm
Product name
Push Pull Electromagnet Solenoid Linear Actuator
Material
Steel
Type
Pull Push
Keyword
Push Pull Tubular Solenoid
Diameter
19mm
Voltage
12/24VDC
Stroke
5mm
MOQ
2pcs
Service
OEM ODM Customised
Certificate
CE/ROHS/ISO9001



Products Specifications
Brand
Landa
Product Series
Tubular solenoid
Model
TU1939
Voltage
12v/24v dc
Power
70w
Force
5N
Stroke
5mm
Duty Cycle
10%
Cable Length
200mm or customization
Materials
steel & enamelled wire
Action Form
Push pull type
Weight (N.W.)
0.12kg
Install style
Screw
Thread size & Deepth(mm)
-
Hi-Pot Test
AC 600V 50/60Hz 2s
Insulation Class
B
Packaging details
Body size(mm)
L39*D19mm
Packaging box size(cm)
standard:21*14*13(cm), custom accepted





Product Features
1. Landa tubular have push and pull type optional, linear motion, Dc power supply, supply reset spring or no reset spring plunger,
can custom the voltage and stroke.
2.Typically used for longer stroke, can also be designed for high force heavy duty applications.
3. Tubular solenoid are excellent used for locking solenoids, whether for doors, security or industrial machiney.
4. Some landa tubular solenoid have single hole mounting holes, easy to install, accepted custom as you needed.

12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 0
12v Pull Push Solenoid 5mm Stroke Mini Linear Tubular Solenoid Actuator 1
Q: Are you trading company or manufacturer?
A: We are original factory.
Q:How to choose a solenoid/electromagnet?
A:Following parameters should be provided: voltage(DC/AC), power, current, resistance, stoke, force, dimension limit, force,residual force, duty cycle, etc.
Q:How long is your delivery time?
A:Generally it is 3-10 days if the goods are in stock, or it is 15-20 days if the goods are not in stock. It is according to
quantity.
Q:What is your terms of payment?
A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shippment.
Q:Is there any extra charges if we want you to print our logo or company name on your products or the packaging?
A:There is no extra charges. Please offer us the LOGO files, and we will make it well on your product.
